UBIQUITI INYECTOR POR U-POE++

Ubiquiti U-POE++ Inyector para alimentar dispositivos UniFi PoE++. Proporciona hasta 60W. Protección contra sobretensiones. Contiene entrada RJ45, cable de CA con toma tierra y salida PoE. Indicador L
Proporciona hasta 60 W de PoE
Apto para UA Hub, G4 PTZ y otros dispositivos PoE
Protección contra sobretensiones, picos de pulsos y sobrecorriente
Contiene entrada de datos RJ45, cable de CA con toma de tierra y salida PoE
Indicador LED para monitorizar el estado



pecifications
ModelU-PoE++
Dimensions106 x 63 x 34 mm (4.2 x 2.5 x 1.3)
Weight210 g (7.4 oz)
Output voltage48V DC @ 1.25A
LAN activity indicatorNo
Gigabit LAN portYes
Remote reset capabilityNo
Reset buttonNo
Rated voltage100—240V AC @ 50/60Hz
Input current1.3A @ 120V AC
0.75A @ 230V AC
Inrush current<100A peak @ 120V AC
<200A peak @ 230V AC
Efficiency85+%
Output ripple1% max.
Switching frequency65 kHz
Line regulation= 1%
Load regulation= 3%
2-pair poweringNo
4-pair poweringPins 1, 2, 4, 5 (+) and 3, 6, 7, 8 (-)
AC connectorIEC-320 C6
Data In / PoERJ45 shielded socket
Surge protectionDifference and common mode
Clamping protection11V data, 60V power
Max. surge discharge1500A (8/20 µs) power
Peak pulse current36A (10/1000 µs) data
Shunt capacitance<5 pF data
Response time<1 ns
Power methodUniversal AC input, 100—240V AC, 50/60Hz, (48V@ 1.25A)
Power supplyAC/DC
Supported voltage range100—240V AC
Max. PoE+ wattage per port by PSE60W
Operating temperature0 to 40° C (32 to 104° F)
Storage temperature-30 to 70°C (-22 to 158° F)
Operating humidity10 to 95% noncondensing
CertificationsCE, FCC, IC, UL, UKCA, KC, CCC, KC, RoHS
