MERCUSYS ROUTER 300MBPS ENHANCED WIRELESS N

300Mbps Enhanced Wireless N Router
MW325R
Maximum coverage – four 5dBi antennas provide up to 500m2 of wireless coverage
Enhanced signal – high gain antennas dramatically increase wireless signal strength, size and stability
300Mbps wireless speed - ideal for HD streaming, online gaming, and large file downloads
Easy installation - intuitive webpage guides you through the setup process in minutes
*Range specifications are based on performance test results. Real performance varies in accordance with applications and environmental conditions.


External Power Supply5VDC/0.6A
Antenna Type4 x 5dBi fixed omni directional antennas
Signal Rate
11n: Up to 300Mbps (Dynamic)

11g: Up to 54Mbps (Dynamic)

11b: Up to 11Mbps (Dynamic)
ButtonReset button
Wireless StandardsIEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency2.4 - 2.5GHz
Reception Sensitivity
270M: -70dBm@10% PER

130M: -72dBm@10% PER

54M: -74dBm@10% PER

11M: -87dBm@10% PER

6M: -92dBm@10% PER

1M: -94dBm@10% PER
Interfaces
3 10/100Mbps LAN ports

1 10/100Mbps WAN port
CertificationsCE, ROHS
Package Contents
300Mbps Enhanced Wireless N Router

MW325R

Power adapter

Quick installation guide

RJ45 Ethernet cable

Environment
Operating temperature: 0°C ~ 40°C (32°F ~ 104°F)

Storage temperature: -40°C ~ 70°C (-40°F ~ 158°F)

Operating humidity: 10% ~ 90%, non-condensing

Storage humidity: 5% ~ 90%, non-condensing
Transmission Power<20dBm
Wireless SecurityWPA-PSK / WPA2-PSK
Wireless Functions
Enable/Disable Wireless Radio, WDS Bridge

WAN Type
Dynamic IP/Static IP/PPPoE/L2TP/PPTP

Management
Access control

Local management

Remote management
DHCP
Server, DHCP Client List

Port ForwardingVirtual server, UPnP, DMZ
Dynamic DNSOray
Firewall SecurityIP and MAC address binding
ProtocolsIPv4
Guest Network2.4GHz guest network
Dimensions (W X D X H)167 x 118 x 33 mm
